Carburated LS1 PCV System/ Catch Can set up need help I have a stock LS1 Carburated with the Edelbrock/ MSD Kit. My valley tray does not have a breather like other later LS motors. I need to set up a PCV system for it but not sure whats the best way to. I don't want pressure problems and start blowing seals or have the motor running like trash. I also have a catch can with an optional breather that can be plugged. How To Install An Oil Catch Can - PowerNation A catch can is designed with baffling on the inside to trap oil and vapor in the bottom side of the reservoir while still allowing the crankcase to breathe freely through a filter that's on the top side. An oil separator is placed in line between PCV hoses. It has a mesh screen and filter material that traps the oil and vapor.
