OMC Cobra Shift Cable Removal Installation Adjustment Instructions Guide. REMOVAL. 1. Remove Outdrive (Not covered in this guide) 2. Disconnect the transom bracket shift cable from the shift bracket located on the engine. 3. Loosen both set screws from the casing guide and then loosen the lock nut and unscrew the casing guide jacket so that ... The best source for Mercruiser OEM parts, marine engines, boat & engine parts, accessories, boating supplies, tools, & aquatic sporting goods.

Notes: (Advanced Throttle Only) (A21 And A41). Mercury Marine remote controls and components modular components parts. Buy a genuine Mercury Quicksilver or aftermarket part. Reference numbers in this diagram can be found in a light blue row below — scroll down to order. Each product #9, A 1, THROTTLE LEVER ASSEMBLY (1 required per assembly).

Mercruiser shift cable adjustment diagram

We have all of the Mercury/Mercruiser remote control throttle/shift cables here for you to choose from. Gen I, Gen II, SAE for outboards, sterndrive and Sportjets engines all at discounted pricing when ordering online. Fast shipping from BAM Marine of Florida. Mercruiser Alpha One Shift Cable Diagram. Mercruiser Alpha One and gen 2 exploded view outdrive drawings. Bell housing parts and Transom plate shift cable Alpha 1 and generation 2. Transom plate. Apr 24, I have replaced the shift and throttle cables on my 92 Mercruiser L. MR and Alpha One Shift. Cable Adjustment Inspection and Readjustment. A letter is being sent to all registered owners of the fol- lowing MerCruiser models ...17 pages

Mercruiser shift cable adjustment diagram. RANSOTO Intermediate Lower Shift Cable Kit Compatible with MerCruiser Stern Drives 1978-Up MC-I, MR, Alpha One and Alpha One Gen II Replace 865436A02 865436A03 18-2190. 3.4 out of 5 stars. 15. $63.50. $63. . 50. Get it as soon as Sat, Jun 26. FREE Shipping by Amazon. The MerCruiser stern drive's shift cable connects the driver controls to the shift control plate. A shift interrupter switch connects to the shift plate and stalls the engine when you shift in and out of gear to help prevent damage to the stern drive. This switch is directly centered in the assembly when the cable ... Step 2.2: Remove any clamps or nylon ties holding the shift cable bellows to the shift cable and the hose. Be aware of the small plastic or rubber insert at the end of the bellows, sealing the bellows to the cable. It is important to reinstall this properly to avoid water leaking into the boat. At this point you may want to also pull the shift ... Trace the shift cable from the shift lever to the propeller on the MerCruiser. A shift arm, the lower shift cable that attaches to the shift arm, the propeller, some metal studs and slots for the cable to rest in when shifting from forward to reverse now are exposed. Jul 13, · Re: MerCruiser Shift cable adjustment That diagram Eric posted is ...

unit shift cable is binding, the shift cutout switch plunger pin will move off center when shifting into and out of FORWARD and REVERSE.) NOTE: If shift cable was damaged during installation, install new shift cable assembly in accordance with instructions contained in sterndrive service manual, then repeat shift cable adjustment procedure. About Press Copyright Contact us Creators Advertise Developers Terms Privacy Policy & Safety How YouTube works Test new features Press Copyright Contact us Creators ... 10. Refer to Figure 9 and connect the throttle cable as follows: a. Move remote control to neutral gear, idle position. b. Connect cable end guide to throttle lever with flat washer and nut. c. Holding throttle cable behind the brass barrel, push it toward the throttle lever. Adjust barrel to align with anchor stud, then connect How to adjust your mercruisier shift cable. boat sticks In forward or reverse. Boat stuck in forward, boat stuck in reverse. Boat clicks when you shift you n...

2-4-C with PTFE Shift cable/throttle cable lubrication points 92-802859A 1 NOTE: Allow for clearance of the cables directly behind the remote control. Cable radius at any one point must not be less than 305 mm (12 in.). General Installation Information IMPORTANT: The control handle friction adjustment must be made prior to installation. When I got back to the dock, I noticed that the shift cable linkage was loose. I tightened it back up but now find that probably 1 out of 2 ...Jul 4, 2015 · Uploaded by SEI Marine Products Mercruiser Alpha One Shift Cable Diagram. Mercruiser shift cable adjustment and install help use when installing and view Mercruiser tech drawings; Mercruiser/MR/Alpha 1 shift cable kit OEM A03 First, examine the condition of the connections on the unit. You will need to replace this cable a new one (P/N OEM A03). Mercruiser R MR tool for shift cable kit adjustment and install, Alpha one, gen 2. Help installing and adjusting. 1/4-28 pipe thread tap for older unit assembly.
